Optimization of Aluminum Casting Process Using PLA-Based Casting Patterns and Analysis of their Thermal Behavior

Y.S. Merkibayev; T.A. Chepushtanova; B. Bazarbay; G. Burshukova; A.M. Berlibek; P. Sherstnev; Christof Sommitsch

doi:10.31643/2028/6445.12

Authors

Y.S. Merkibayev Satbayev University
T.A. Chepushtanova Satbayev University
B. Bazarbay Satbayev University
G. Burshukova Satbayev University
A.M. Berlibek Satbayev University
P. Sherstnev Graz Tehnology University
Christof Sommitsch Graz Tehnology University

DOI:

https://doi.org/10.31643/2028/6445.12

Keywords:

3D printing, investment casting, aluminum alloys, additive manufacturing, industrial manufacturing, innovative manufacturing processes.

Abstract

This paper presents the results of experimental and numerical studies of the casting process of 99.85% pure aluminum using investment-casting technologies with patterns produced by additive manufacturing. The influence of pouring temperature, mold-filling time, and gating-system design on porosity formation and casting quality was analyzed. It was established that increasing the pouring temperature within the range of 700–800°C leads to increased porosity due to higher gas solubility and intensified turbulence of the melt flow. It was shown that the separating gating system ensures a minimum number of defects compared to top and bottom metal-feeding systems. In addition, thermal analysis of PLA and a glass-fiber-reinforced PLA composite was carried out. Pure PLA was found to burn out almost completely (residue about 2.4%), whereas the composite was characterized by a high residual content (~43.6%), which may negatively affect mold quality. The simulation results obtained using the AutoCAST software package showed good agreement with the experimental data and confirmed the effectiveness of numerical modeling for optimization of casting processes. It was established that the optimal pouring-temperature range for aluminum is 720–760°C. The obtained results confirm the potential of using PLA in investment casting technology and make it possible to improve the quality of aluminum castings under industrial production conditions.

Downloads

Download data is not yet available.

Author Biographies

Y.S. Merkibayev, Satbayev University

Ph.D., Senior Lecturer, Department of Metallurgy and Mineral Processing, O.A. Baikonur Mining and Metallurgical Institute, Satbayev university, Almaty, Kazakhstan. ORCID ID: https://orcid.org/0000-0003-3869-6835

T.A. Chepushtanova, Satbayev University

Doctor Ph.D., Candidate of Technical Sciences, Associate Professor of the Department of Metallurgy and Mineral Processing, O.A. Baikonurov Mining and Metallurgical Institute, Satbayev University, Almaty, Kazakhstan. ORCID ID: https://orcid.org/0000-0002-6526-0044

B. Bazarbay, Satbayev University

Ph.D., lecturer, A. Burkitbaev Institute of Power Engineering and Mechanical Engineering, Department of Mechanical Engineering, Satbayev University, Almaty, Kazakhstan. ORCID ID: https://orcid.org/0000-0002-7387-1654

G. Burshukova, Satbayev University

Ph.D., Associate Professor, Department of Transport and Logistics, Satbayev University, Almaty, Kazakhstan. ORCID ID: https://orcid.org/0000-0001-9200-2780

A.M. Berlibek, Satbayev University

Doctoral student, Master of Science in the Department of Metallurgy and Mineral Processing, O.A. Baikonurov Mining and Metallurgical Institute, Satbayev University, Almaty, Kazakhstan. ORCID ID: https://orcid.org/0009-0001-0163-6911

P. Sherstnev, Graz Tehnology University

Doctor Ph.D., Graz University of Technology, Austria. ORCID ID: https://orcid.org/0009-0007-2351-1910

Christof Sommitsch, Graz Tehnology University

Ph.D., Professor, Graz University of Technology, Austria, Director of the Institute of Materials Science, Welding and Metallurgy. ORCID ID: https://orcid.org/0000-0002-6854-4851

References

Linder J, Axelsson M, Nilsson H. Influence of porosity on fatigue life of aluminium castings. Int. J. Fatigue. 2006; 28:1752–1758. https://doi.org/10.1016/j.ijfatigue.2006.01.001

Campbell J. Complete Casting Handbook; Butterworth-Heinemann: Oxford, UK. 2011. https://www.researchgate.net/publication/259486719_Complete_Casting_Handbook_2011

Ravi B. Casting simulation and optimization: Benefits, bottlenecks and best practices. Indian Foundry J. 2008, 1–12. https://www.researchgate.net/profile/B-Ravi-2/publication/228975218_Casting_Simulation_and_Optimisation_Benefits_Bottlenecks_and_Best_Practices/links/53f0dbac0cf23733e812f5a0/Casting-Simulation-and-Optimisation-Benefits-Bottlenecks-and-Best-Practices.pdf

Flemings MC. Solidification Processing; McGraw-Hill: New York, USA. 1974. https://doi.org/10.1002/9783527603978.mst0173

Choudhari CM, Narkhede BE, Mahajan SK. Casting design and simulation using AutoCAST-X. Procedia Mater. Sci. 2014; 6:786–797. https://doi.org/10.1016/j.mspro.2014.07.095

Barsawade PB, Santhy K, Gholap M, Salot M. Grain refinement of Al-Ti master alloy on as cast and heat treated Al-Si-Mg alloy. 14TH International Conference on Materials Processing And Characterization 2023. 2024. https://doi.org/10.1063/5.0192508

Sigworth GK. Refining of Secondary Aluminum: Important Chemical Factors. Int. J. Minerals, Metals & Materials Society. 2021; 5:7–18. https://doi.org/10.1007/s11837-021-04774-z

Campbell J. Entrainment defects. Mater. Sci. Technol. 2006; 22:127–145. https://doi.org/10.1179/174328406X74248

Stefanescu DM. Science and Engineering of Casting Solidification; Springer: New York, USA. 2009. https://link.springer.com/book/10.1007/978-3-319-15693-4

Kent D Carlson, Beckermann C. Prediction of Shrinkage Pore Volume Fraction Using a Dimensionless Niyama Criterion. Metallurgical and Materials Transactions A. 2009; 7:52–63. https://doi.org/10.1007/s11661-009-0055-3

Dabade UA, Bhedasgaonkar RC. Casting defect analysis using simulation. Procedia CIRP. 2013; 7:616–621. https://doi.org/10.1016/j.procir.2013.06.042

Nimbulkar SL, Dalu RS. Optimization of gating system. Perspect. Sci. 2016; 8:39–42. https://doi.org/10.1016/j.pisc.2016.03.001

Ravi B. Metal Casting: Computer-Aided Design and Analysis; PHI Learning: New Delhi, India. 2015. http://pdfcoffee.com/computer-aided-casting-design-and-simulation-pdf-free.html

Ngo TD, Kashani A, Imbalzano G. Additive manufacturing (3D printing): A review. Compos. Part B. 2018; 143:172–196. https://doi.org/10.1016/j.compositesb.2018.02.012

Gibson I, Rosen D, Stucker B, Khorasani A. Additive Manufacturing Technologies; Springer: New York, USA. 2020. https://doi.org/10.1007/978-3-030-56127-7

Farah S, Anderson DG, Langer R. Physical and mechanical properties of PLA. Adv. Drug Deliv. Rev. 2016; 107:367–392. https://doi.org/10.1016/j.addr.2016.06.012

Tsuji H. Poly (lactic acid): Synthesis and Applications; Wiley: Hoboken, USA. 2010. https://www.researchgate.net/publication/216770320_PolyLactic_Acid_Synthesis_Structures_Properties_Processing_and_Applications

Randall J. Polylactic acid technology. Natural Fibers, Biopolymers, and Biocomposites. 2005; 12:1841–1846. https://doi.org/10.1201/9780203508206.ch16

Pickering KL, Efendy MGA, Le TM. Fiber-reinforced composites. Compos. Part A. 2016; 83:98–112. https://doi.org/10.1016/j.compositesa.2015.08.038

Fu SY, Lauke B. Effects of fiber length and orientation. Compos. Sci. Technol. 1996; 56:1179–1190. https://doi.org/10.1016/S0266-3538(96)00072-3

Thomason JL. Glass fibre sizing and interfacial bonding. Compos. Part A. 2002; 33:1641–1652. https://doi.org/10.1016/j.compositesa.2019.105619

Chacón JM, Caminero MA, García-Plaza E, Nunez PJ. Additive manufacturing of PLA structures using fused deposition modelling: Effect of process parameters on mechanical properties and their optimal selection. 2017; 124:143-157. https://doi.org/10.1016/j.matdes.2017.03.065

Torrado Perez AR, Roberson DA. Failure Analysis and Anisotropy Evaluation of 3D-Printed Tensile Test Specimens of Different Geometries and Print Raster Patterns. Jornal of Failure Analysis and Prevention. 2016; 1–4:10–19. https://doi.org/10.1007/s11668-016-0067-4

Liu X, Petinakis E, Long Yu, Cameron Way. Biodegradation and thermal decomposition of poly(lactic acid)-based materials reinforced by hydrophilic fillers. Polymer Degradation and Stability. 2010; 95(9):1704-1707. https://doi.org/10.1016/j.polymdegradstab.2010.05.027

Chacón JM, Caminero MA, García-Plaza E, Núñez PJ. Additive manufacturing of PLA structures using FDM: Mechanical and thermal properties. Materials. 2017; 10:124. https://doi.org/10.1016/j.matdes.2017.03.065

Chepushtanova TA, Merkibayev YS, Mamyrbayeva K K, Sarsenbekov T, Mishra B. Mechanism and technological results of sulfidation roasting of oxidized compounds. . Kompleksnoe Ispolzovanie Mineralnogo Syra = Complex Use of Mineral Resources. 2025; 332(1):119-132. https://doi.org/10.31643/2025/6445.11

Chepushtanova TA, Merkibayev YS, Mamyrbayeva KK, Mishra B, Kuldeyev YI. Processing of the zinc-lead-bearing flotation middlings by sulfidizing roasting with pyrrhotites production by predicted properties. Non-Ferr. Met. 2022; 2: 15-24. https://doi.org/10.17580/nfm.2022.02.03

Merkibayev YS, Chepushtanova ТА, Berlibek АM, Tolegenova АК, Nugumarov ShТ. Development of technology for the productio of aluminum castings using 3d printing of models and lost-was casting. Kompleksnoe Ispolzovanie Mineralnogo Syra=Complex Use of Mineral Resources. 2026; 337(2):108-116.https://doi.org/10.31643/2026/6445.22
