Application of bank protection structures for regulation of channel processes in the lower reaches of the Shu River

N.K. Yerzhanova; Zh.A. Mussin; A.D. Altynbekova

doi:10.31643/2028/6445.24

Authors

N.K. Yerzhanova L.N. Gumilyov Eurasian National University
Zh.A. Mussin Kazakh Scientific Research Institute of Water Economy
A.D. Altynbekova L.N. Gumilyov Eurasian National University

DOI:

https://doi.org/10.31643/2028/6445.24

Keywords:

bank protection spur; erosion protection; river channel regulation; polyethylene beams; hydraulic structure; prefabricated modular structure; flood regulation; hydrological variability; discharge exceedance probability.

Abstract

The article presents the application of bank protection structures for regulating channel processes in the lower reaches of the Shu River under conditions of high hydrological variability. The analysis is based on long-term hydrological observations conducted at the Tashutkul (Tasotkel) hydrological station over the period 1967–2022. A statistical assessment of annual maximum and mean discharges, including measures of variability, skewness, and exceedance probability, revealed the occurrence of rare but extreme flood events that significantly influence channel deformation and bank erosion in reaches composed of sandy–gravel alluvial deposits. A probabilistic hydrological analysis was applied to justify the design hydraulic loads acting on river training structures. Based on the identified hydrological and morphological risks, an improved prefabricated modular floating bank protection spur was developed for river engineering and channel regulation. The proposed structure provides adjustable permeability, promotes flow energy dissipation, and reduces local scour intensity under different flow conditions. The obtained results may be applied in the design and operation of adaptive bank protection structures for the lower reaches of the Shu River and other rivers characterized by pronounced channel instability and hydrological variability.

Downloads

Download data is not yet available.

Author Biographies

N.K. Yerzhanova, L.N. Gumilyov Eurasian National University

Master of Agricultural Sciences, Senior Lecturer, L.N. Gumilyov Eurasian National University, 010000, Satbaev st., 2, Astana, Kazakhstan. ORCID ID: https://orcid.org/0000-0002-0671-945X

Zh.A. Mussin, Kazakh Scientific Research Institute of Water Economy

Candidate of Technical Sciences, Kazakh Scientific Research Institute of Water Economy, 080016, Taraz, Kazakhstan. ORCID ID: https://orcid.org/0000-0002-8727-5749

A.D. Altynbekova, L.N. Gumilyov Eurasian National University

PhD, Senior Lecturer, L.N. Gumilyov Eurasian National University, Satbaev st., 2, 010000, Astana, Kazakhstan. ORCID ID: https://orcid.org/0000-0003-1010-9328

References

Didovets I, Lobanova A, Krysanova V, Menz C, Babagalieva Z, Nurbatsina A, Hattermann F. Central Asian Rivers under Climate Change: Impacts assessment in eight representative catchments. Journal of Hydrology: Regional Studies. 2021; 34:100779. https://doi.org/10.1016/j.ejrh.2021.100779

Kaliyeva K, Punys P, Zhaparkulova Y. The impact of climate change on hydrological regime of the transboundary River Shu Basin (Kazakhstan–Kyrgyzstan): forecast for 2050. Water. 2021; 13(20):2800. https://doi.org/10.3390/w13202800

Issaldayeva S, Alimkulov S, Raimbekova Z, Bekseitova R, Karatayev M. The climatic and river runoff trends in Central Asia: The case of Zhetysu Alatau region, the south-eastern part of Kazakhstan. Heliyon. 2023; 9(7):e17897. https://doi.org/10.1016/j.heliyon.2023.e17897

Kundzewicz ZW, Kanae S, Seneviratne SI. Flood risk and climate change: global and regional perspectives. Hydrological Sciences Journal. 2014; 59(1):1-28. https://doi.org/10.1080/02626667.2013.857411

Chen F, Yuan Y, Trouet V, Büntgen U, Esper J, Chen F, Zhang H. Ecological and societal effects of Central Asian streamflow variation over the past eight centuries. Climate and Atmospheric Science. 2022; 5(1):27. https://doi.org/10.1038/s41612-022-00239-5

Yue S, Pilon P, Phinney BOB. Canadian streamflow trend detection: impacts of serial and cross-correlation. Hydrological Sciences Journal. 2003;48(1):51-63. https://doi.org/10.1623/hysj.48.1.51.43478

Hamed KH. Trend detection in hydrologic data: The Mann–Kendall trend test under the scaling hypothesis. Journal of hydrology. 2008;349(3-4):350-363. https://doi.org/10.1016/j.jhydrol.2007.11.009

Giupponi C, Gain AK. Integrated water resources management (IWRM) for climate change adaptation. Regional Environmental Change. 2017;17(7):1865-1867. https://doi.org/10.1007/s10113-017-1173-x

SU1070257A1 Russia. Skvozna beregozashchitna shpora [Permeable bank protection spur]. Shuminsky VD. Patent of the USSR. 1982. (in Russ.).

Rakhimova M, Liu T, Bissenbayeva S, Mukanov Y, Gafforov KS, Bekpergenova Z, Gulakhmadov A. Assessment of the Impacts of Climate Change and Human Activities on Runoff Using Climate Elasticity Method and General Circulation Model (GCM) in the Buqtyrma River Basin, Kazakhstan. Sustainability. 2020; 12(12):4968. https://doi.org/10.3390/su12124968

Tazhiyev S, Murtazin Y, Rakhimova V, Rakhmetov I, Adenova D, Koshpanova K, Sotnikov Y, Abdizhalel M, Akylbayeva A, Yerezhep D. Applied Hydrogeological Assessment and GIS-Based Modeling of Transboundary Aquifers in the Shu River Basin. Water. 2025; 17(16):2476. https://doi.org/10.3390/w17162476

Yapiyev V, Ongdas N, Saidaliyeva Z, Zhiyenbek A, Smogulova T, Baigaliyeva M, Prikaziuk E. Baseline information and regionalization of the large river basins of Kazakhstan. Frontiers in Water. 2025; 7:1601671. https://doi.org/10.3389/frwa.2025.1601671

Bolatova A, Krysanova V, Lobanova A, Bolatov K. Assessment of climate change impacts for two tributary basins of the Irtysh River in Kazakhstan. Climate Research. 2023; 91:159-174. https://doi.org/10.3354/cr01726

Tursunova A, Nurbatsina A, Salavatova Z, Huthoff F. Sustainability Challenges in Kazakhstan’s River Systems: Assessing Climate-Induced Hydrological Changes. Sustainability. 2025; 17(8):3405. https://doi.org/10.3390/su17083405

RU2730607C1 Russia. Podvizhnaya beregozashchitnaya shpora [Movable bank protection spur]. Kupchikova NV. Patent of the Russian Federation. 2020. (in Russ.).

Yerzhanova NK, Sennikov MN, Transgranichnoe sotrudnichestvo v sfere upravleniya riskami pavodkov [Transboundary Cooperation in Flood Risk Management], Mezhdunarodnaya nauchno-prakticheskaya konferentsiya «Teoreticheskie i prikladnie problemi geografii» [International Scientific and Practical Conference «Theoretical and Applied Problems of Geography»], Astana, 20 May. L.N. Gumilyov Eurasian National University. 2024, 244-248. (in Russ.).

US20240279892A1 USA. River training structure, system comprising river training structure, and method for training a river. Jan SR. US international patent application. 2021.

KZ27570 Kazakhstan. Sborno-razbornaya konstruktsiya plavayushchei beregozashchitnoi shpori [Prefabricated modular floating bank protection spur]. Bakbergenov NN, Musin Zh. Patent of the Kazakhstan. 2013. (in Russ.).

Sennikov MN, Yerzhanova NK, Sovershenstvovanie upravleniya transgranichnimi vodnimi resursami po Shu-Talasskomu basseinu Respubliki Kazakhstan [Improving the management of transboundary water resources in the Shu-Talas basin of the Republic of Kazakhstan], Materiali Mezhdunarodnoi konferentsii SVO VEKTsA «Problemi upravleniya rechnimi basseinami v usloviyakh izmeneniya klimata» [Proceedings of the International Conference of the North-Eastern European Central Asian Region «Problems of River Basin Management in the Context of Climate Change»], Tashkent, 18-19 May, 2017. NITs MKVK. 2017, 208. (in Russ.).

Sennikov MN, Yerzhanova NK, Prognoznoe povishenie vodoobespechennosti po regulirovaniyu vodnimi resursami Zhambilskoi oblasti [Projected Increase in Water Availability for Water Resources Regulation in Zhambyl Oblast], Mezhdunarodnaya nauchno-prakticheskaya konferentsiya Innovatsionnie i prakticheskie resheniya uskorennogo vosstanovleniya produktivnosti degradirovannikh oroshaemikh zemel KazNIIVKh [International Scientific and Practical Conference Innovative and Practical Solutions for Accelerated Restoration of Degraded Irrigated Land Productivity], Taraz, 20 May, 2022. KazNIIVH. 2022, 68-72. (in Russ.).

Khalimbetov AB, Bakiev MR, Khudaiberganov HA, Sovershenstvovanie konstrukcii i metodov rascheta kombinirovanny`x damb na predgorny`x uchastkax rekax [Improvement of the design and calculation methods of combined dams on foothill river sections]: monograph. Tashkent: NIU TIIIMSKH. 2022, 100. (in Russian).

Ambartsumyan GA, K voprosu gidromekhanicheskogo rascheta skvoznoi shpory s gidravlicheskim barerom [On the problem of hydromechanical design of a permeable spur with a hydraulic barrier] Izvestiya Akademii nauk Armyanskoi SSR. Seriya tekhnicheskikh nauk. Gidravlika, gidrotekhnika. – 1968. – T. XXI, № 5. – p. 32–37 (in Russ.).

Levi II, Dinamika ruslovykh potokov [Dynamics of channel flows]. 2-e izd., pererab. i dop. Leningrad: Gosenergoizdat. 1957, 223.

SP RK 3.04-107-2014, Nagruzki i vozdeistviya na gidrotekhnicheskie sooruzheniya (volnovye, ledovye i ot sudov) [Loads and impacts on hydraulic structures (wave, ice and ship loads). Astana: Committee for Construction]. Astana: Komitet po delam stroitel'stva, ZHKKh i upravleniya zemel'nymi resursami MNE RK. 2015.

Levi I I. Dvizheniya rechnykh potokov v nizhnikh biefakh gidrotekhnicheskikh sooruzheniy [Movements of river flows in downstream reaches of hydraulic structures]. M.-L.: Gosenergoizdat. 1955, 256.

Mikhasek AA, Malyugin NR. Vliyanie fil'tratsii v tele aktivnogo beregozaschitnogo sooruzheniya na kharakteristiki obtekayushchego potoka [Influence of filtration through the body of an active bank protection structure on the characteristics of the surrounding flow]. Gradostroitel'stvo i arkhitektura. 2019; 9(3):92–98. https://doi.org/10.17673/Vestnik.2019.03.12

Talmaza V F. Nekotorye osobennosti dvizheniya vlekomykh nanosov na rekakh gorno-predgornoi zony [ome features of bedload sediment transport in rivers of mountainous and foothill regions]. Dinamika i termika rek. Moscow: Stroiizdat. 1973.

Rustembek uulu Abdinazar, Meyman uulu Bektur. Rezul'taty model'nykh issledovanii regulyatsionnykh sooruzhenii na uchastke reki Chu [Results of physical model studies of river training structures on the Shu River reach]. Vestnik KRSU. 2018; 18(8):134–137.
